Manifold HVAC 10
Introducing the Manifold PCE-HVAC 10, the ultimate solution for all your HVAC installation, maintenance, and optimization needs. Our product offers a comprehensive range of features including assistance with heat pump, air conditioning, refrigerant pressure testing, temperature testing, and installation of various refrigerants such as R410a, R32, R22, and R1234YF…

Feature:
  1. - Measurement Range: -1 ... +60 bar
  2. - Resolution: 0.01 bar
  3. - Accuracy: ±0.5% FS (Full Scale).
  4. - 83 refrigerants stored in the device
  5. - 2-way valve block with 3 connectors 7/16" – UNF
  6. - Includes 2 NTC clamp-on temperature sensors
  7. - Temperature measurement from -10 ... +200 °C

Manifold HVAC 10

  • Temperature NTC
    Measurement Range -10°C ... +200°C
    Resolution 0.1°C
    Accuracy ±(1°C + 1 Digit)

    Pressure
    Measurement Range -1 bar ... +60 bar
    Resolution 0.01 bar
    Accuracy ±0.5% FS (Full Scale)

  •

    Units MPa, kPa, psi, bar, °F, °C
    Connection Type 3 x 7/16" – UNF
    Display Type LCD
    Automatic Shutdown 30 min.
    Measuring Medium Refrigerant (see manual)
    Battery Type AA Battery (1.5V)
    Menu Language English
    Protection Class IP42
    Weight 768 g
    Device Weight with Accessories 2185 g
    Device Weight with Accessories and Packaging 2271 g
    Dimensions  204 x 116 x 65 mm (L x W x H)
    Dimensions Including Packaging  345 x 275 x 105 mm (L x W x H)
